Features
. Clamp open 28mm
. TRUE RMS, Data hold, Duty cycle test, REL test
. Non-contact voltage testing with visible alarm
. Clamp light display, or backlight display
. Portable design, easy use
. Full function protection, strong anti-interferential performance
. CE standard design, improving the safety of test
Technical data | MC216 |
Basic function | Range | Basic Accuracy |
DCV |
600mV / 6V / 60V / 600V | ±(0.5%+3) |
ACV | 6V / 60V / 600V | ±(0.8%+5) |
DCA | 2A / 200A / 600A | ±(2.0%+30) |
ACA | 2A / 20A / 200A / 600A | ±(2.0%+30) |
Resistance | 600Ω / 6kΩ / 60kΩ / 600kΩ / 6MΩ / 60MΩ | ±(0.8%+3) |
Capacitance | 6nF/60nF/600nF/6uF/60uF/600uF/4mF/40mF | ±(3.5%+20) |
Fequency |
10Hz/100Hz/1kHz/10kHz/100kHz/1MHz/10MHz | ±(0.1%+3) |
Temperature |
-40℃~1000℃ |
±(1.0%+5) |
0℉~1832℉ | ±(1.0%+5) |
Special function |
TRMS | √ |
NCV | √ |
Data hold | √ |
| Function protection | √ |
Diode test | √ |
Clamp light | √ |
| Backlight display | √ |
Continuity alarm | Less than 50Ω, it displays “OL” if over 600Ω |
Low battery indicator | Approx. less than 2.4 V |
Auto power off | About 15 minutes
|
General characteristic |
Input impedance | 10MΩ |
Sampling rate | 3 times/s |
AC frequency response | Current 40-1kHz / Voltage 40-2kHz |
Operation method |
Manual or Auto range |
Max. display | 6000 |
Clamp open | 28mm |
Battery | 3V AAA×2 |
Meter weight | 200g（including battery） |
Meter size | 210×110×45mm |
